When choosing a corner toilet, knowing the precise dimensions is the first step to ensure it fits your bathroom layout — especially in compact or irregular spaces.
While our previous guides cover installation, rough-in measurement, and space-saving tips, this post focuses on exact dimension data and what each specification means in real-world use.
Ⅰ. Understanding Corner Toilet Dimensions
Corner toilets are designed with a triangular tank that fits neatly into a 90° angle, allowing the bowl to extend diagonally into the room. This structure helps maximize available floor space while maintaining full-size comfort.
However, not all corner toilets are created equal — slight differences in projection, seat height, or base size can determine whether the model will fit comfortably. Below, we’ll break down the full dimensions of our corner toilet model and explain how each measurement affects fit and function.
💭 Need help checking your available space first? See our guide on How to Measure for a Corner Toilet.
Ⅱ. Full Dimension Breakdown
Here’s a detailed specification chart for our corner toilet model — designed to meet ADA comfort standards and U.S. plumbing requirements.
|
Part |
Measurement |
Key Note |
|
Wall Clearance(Side Distance) |
25.2 inches |
Space from the farthest rim edge to each side wall — ensures balanced installation in tight corners. |
|
Total Depth (Corner to Rim) |
32.7 inches |
Distance from the wall corner to the front edge of the bowl. Recommended clearance: at least 35 inches for comfortable legroom. |
| Seat Height |
17.2 inches |
ADA comfort height; easier for seniors or users with mobility needs. |
| Bowl Type & Length |
Elongated bowl – 18.5 inches |
Space-saving yet maintains full seating comfort. |
| Flush Valve Diameter |
3 inches |
Strong 360° siphon flush with optimized water efficiency. |
| Inlet Valve Connection |
7/8" |
Standard angle shut-off valve size for water supply connection. |
| Rough-In Distance |
12 inches |
Standard rough-in compatible with most U.S. drain setups. |
| Bolt Spread |
6 inches |
Typical floor bolt spacing for secure mounting. |
| Trapway Diameter |
3" flange connection; 2" internal trapway |
Meets U.S. standard flange requirements; includes wax ring and anti-leak alignment kit. |
|
Base Footprint(D × W) |
20" × 9.4" |
/ |
|
Overall Dimensions (D × W × H) |
32.7" × 13.8" × 30.8" |
Compact design that fits comfortably even in a 5×5 ft bathroom. |
Ⅲ. How These Dimensions Affect Fit and Function
Each specification above plays a role in both comfort and compatibility:
- 32.7-inch total depth allows full seating comfort while keeping projection shorter than most regular one-piece toilets (typically around 28–31 inches straight out from the wall).
- 17.2-inch seat height complies with ADA comfort height, reducing strain on knees and joints.
- 2-inch trapway and 3-inch flush valve work together to deliver an efficient, clog-resistant flush — matching U.S. residential standards.
- Compact 9.4”×20” base footprint helps minimize floor obstruction and provides extra room for cleaning or repositioning.
💡 Curious how this compares to regular toilets? Read Corner Toilet vs. Regular Toilet: What’s the Real Difference?
Ⅳ. Space Planning Tips
Even though corner toilets save significant space, accurate measurement remains essential.
Here are a few planning guidelines:
- If your space allows, leave about 2 inches of clearance between the tank and both corner walls to make installation and maintenance easier.
- For comfortable legroom, allow at least 35 inches from the corner to any obstacle (vanity, door, or wall).
- Keep 15 inches minimum between the bowl’s centerline and sidewalls — the same spacing required by most plumbing codes.
- Verify the rough-in distance (12 inches from side wall to flange center) before installation.
🌐 If you’re deciding which side or angle fits your layout best, check our layout guide: Which Corner Is Best for a Toilet?
🔍 For full step-by-step instructions, visit our Corner Toilet Installation Guide.
Final Thoughts
Compact yet comfortable — our corner toilet delivers practical design without compromise.
With a 32.7" projection, 17.2" ADA comfort height, and 12" standard rough-in, it’s the perfect solution for maximizing space while meeting all U.S. installation standards.
If you’re planning a renovation or working with a tight floor plan, a properly measured corner toilet can transform your small bathroom into a functional, modern space.
Explore more specifications or shop the item directly at Simple Project.
